Bobcat has launched new Stage V versions of its M-Series S630 and S650 skid-steer loaders. Customers will now have a wider selection in this size of machine, with a choice between the new M-Series S630/S650 models and the more advanced R-Series S66/S76 machines.
The new S630 combines manoeuvrability in tight areas with the reach and visibility needed for applications such as dumping materials over walls, backfilling or loading flatbed trucks. It has a rated operating capacity of 1012kg and a tipping load of 2023kg. The S650 model features vertical lift path boom arms suited to lift and carry, as and material-handling applications. The S650 has a rated operating capacity of 1227kg and a tipping load of 2455kg.
Both machines are powered by the Bobcat D24 engine, featuring a Bosch fuel injection system. With the engine situated transversally in the S630/S650, these models have maintained their compact size, allowing the machines to operate and turn in the same small tight spaces.
New engine technology results in lower fuel consumption - the first engine oil service interval has been extended to 500 hours and improved fuel filtration means less frequent filter replacements. The S630/S650 are also equipped with Versatile Duty Tyres which have a bi-directional design for most common mixed surfaces.
Among other benefits of the new machines, operator comforts include:
Heat or air conditioning option.
Cloth suspension seat
Auto Ride control (option) – improves the operator’s comfort and machine stability.
The base S630/S650 models are equipped with a new 'Deluxe' control panel offering a selection of most of the languages in Europe. Every machine is also equipped with Bobcat Telematics solutions. The control panel also reduces the risk of misuse, thanks to the keyless start function. Options such as High Flow or 2-Speed can also be locked, if necessary, and protected with passwords.
New after-treatment technology (DPF) works automatically, without any interaction during normal operation. If necessary, this technology can be easily managed from the menu in the Deluxe control panel, which enables operators to monitor the machine and exhaust after-treatment. The new automatic multi-step engine low-idle sequence in cold conditions further improves engine performance.
On machines equipped with selectable joystick controls, the auto-idle feature reduces the engine speed to low idle when the joysticks are in neutral position and have not been used for about five seconds. Auto-idle allows for quieter overall operation and reduced fuel consumption.
Lastly, the standard warranty has been extended to two years (or 2000 hours) with 'Protection Plus' providing up to five years of coverage.
